Get An Ozone & Oxygen Concentrator

Pro-O2 Max Oxygen Concentrators

At Pure Aquatics in Port Macquarie, we supply a great selection of ozone and oxygen concentrators. The Max series of oxygen concentrators is the solution for any industrial/non-medical oxygen concentrator application.

FEATURES:

  • Built-in a lightweight aluminium cabinet, providing a durable housing unit that protects the circuitry and compressor from the outside environment.
  • Available in both 115 volt/60 hertz and 230 volt/50 hertz configurations.
  • Comes in 5, 8, or 10 litres per minute (LPM) arrangements.
  • Designed with a built-in moisture separator to remove any water vapour before it enters the sieve beds. This increases not only the purity of the oxygen provided but also maximises the lifespan of the sieve bed module.
  • Spring-Mounted Thomas Compressor to help reduce both the vibration and overall sound of the machine.
  • The compressor sits atop two fans that help keep the operating temperature inside the box to a minimum while also allowing for easy venting of exhaust gases through the bottom of the unit.
  • Has two removable side cabinets, designed to allow easy servicing and accessibility to any part of the machine.
  • The Max series has both a replaceable cabinet filter, which is designed to minimise the chances of environmental debris from working its way into the machine, as well as a replaceable compressor inlet filter that acts as a secondary screen against particles entering the compressor.



  • Comes equipped with a proven modular sieve bed design, in which one cylinder is constantly supplying purified oxygen while the other is venting the captured nitrogen.
  • Oxygen purity for the Max series is 90.0 (+5.0/-3.0) % purified oxygen.
  • Oxygen passes through an oxygen sensor attached to the circuit board and measures the purity of the oxygen via ultrasonic waves. If the purity were to drop below 85.0%, the board will alarm to alert that there has been a drop in the purity.
  • A loss of power alarm is standard on all Max series machines, which is triggered if the machine were to unexpectedly lose power.
  • Attached are four rubber skid-proof feet, guaranteeing a machine that does not slide or tip easily, while also allowing for the removal of the feet, for the ability to mount the machine to any stable surface.
  • The machine weighs 62 pounds, or 28.13 kilograms once it is completely assembled.
  • The dimensions of the machine are 22.6 × 10.5 × 26.8 inches or 57.4 × 26.7 × 68.1 centimetres.
    Outlet pressure for the various machines is as follows:
  • Max 5 LPM = 7.0 PSI/ 0.483 Bar/ 0.477 ATM
  • Max 8 LPM = 15.0 PSI/ 1.034 Bar/ 1.021 ATM
  • Max 10 LPM = 19.0 PSI/ 1.31 Bar/ 1.293 ATM
  • The machine has been tested to and is compliant with IPX-1 water ingress testing
Learn More

Features & Treatments

The Pure Aquatics air drier assembly is for use in the pre-treatment of air for ozone generators and oxygen concentrators.

FEATURES:

  • Twin clear 10″ housing
  • Flow rate up to 10lpm
  • Course inlet filter
  • 1 micron pleated pre-filter
  • Silica desiccant indicator gel cartridge with 1kg of media (changes pink when saturated)
  • 3/4″ female fittings for flexible installation option


Ozone generators: If running an ozone generator on air, it is important to filter the incoming air and strip moisture from it to prevent the production of nitric acid, prevent damage to the corona cell and increase output.

Oxygen concentrators: In some applications, excess moisture can be present in the air that can cause premature exhaustion of sieve beds in oxygen concentrators. By filtering the air to 1 micron, excess dirt, dust and salts are minimised, increasing the efficiency of the oxygen concentrator. The addition of the desiccant media strips moisture from the air further protecting the sieve beds in the oxygen concentrator.

Get in Touch
A room with tanks — Pure Aquatics in Waychioe, NSW
